Product Summary

The ULN2003AFWG is a high-voltage, high-current darlington driver. It is comprised of seven NPN darlington pairs. All units feature integral clamp diodes for switching inductive loads. The applications of the ULN2003AFWG are relay, hammer, lamp and display(LED) drivers.

Parametrics

ULN2003AFWG absolute maximum ratings: (1)output sustaining voltage:-0.5V to 50V; (2)output current:500mA/ch; (3)input voltage:-0.5V to 30V; (4)clamp diode reverse voltage:50V; (5)clamp diode forward current: 500mA; (6)power dissipation: 0.54W; (7)operating temperature:-40℃ to 85℃; (8)storage temperature:-55℃ to 150℃.

Features

ULN2003AFWG features: (1)output current(single output) 500mA MAX.; (2)high sustaining voltage output 50V min.; (3)output clamp diodes; (4)inputs compatible with various types of logic; (5)package type-AFW: SOL-16pin.

Diagrams

ULN2003AFWG pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ULN2003AFWG
ULN2003AFWG

Other


Data Sheet

Negotiable
ULN2003AFWG(5,EL,M
ULN2003AFWG(5,EL,M

Toshiba

Transistors Darlington 7CH. 50V/.5A IFD IC

Data Sheet

Negotiable
ULN2003AFWG(O,M)
ULN2003AFWG(O,M)

Toshiba

Transistors Darlington 7-ch 500mA 50V 2.7 kOhm 5V CMOS

Data Sheet

0-1: $0.15
1-10: $0.14
10-100: $0.13
100-250: $0.12
ULN2003AFWG(O,NEHZ
ULN2003AFWG(O,NEHZ

Toshiba

Transistors Darlington 7-Ch 500mA 50V NPN Darlington Trans

Data Sheet

0-1600: $0.18
1600-2000: $0.16
2000-3000: $0.16
3000-5000: $0.14
ULN2003AFWG(O,EL,M
ULN2003AFWG(O,EL,M

Toshiba

Transistors Darlington 7-ch 500mA 50V 2.7 kOhm 5V CMOS

Data Sheet

Negotiable
ULN2003AFWG(5,M)
ULN2003AFWG(5,M)

Toshiba

Transistors Darlington 7CH. 50V/.5A IFD IC

Data Sheet

Negotiable
ULN2003AFWG(ONEHZA
ULN2003AFWG(ONEHZA

Toshiba

Transistors Darlington INTERFACE DRIVER PB-FREE W / TTL

Data Sheet

Negotiable
ULN2003AFWG(SC,M)
ULN2003AFWG(SC,M)

Toshiba

Transistors Darlington 7CH. 50V/.5A IFD IC

Data Sheet

Negotiable
